Hafele Metalla Narrow Aluminium Profile Hinge

Tk. 1,250

Key Features :

  • With two silicone oil dampers integrated in hinge cup.
  • Integrated soft closing.
  • Salt spray test: 48 hours (Passed).
  • Cycle test: 200,000 cycle (Passed).

Hafele Metalla 510 Narrow Aluminium Profile Hinge Features :

Product Name Metalla 510 Narrow Aluminium Profile Hinge EN 15570
Code 311.46.593
Brand Hafele
Product Type Hinge
Colour/Finish Nickel plated
Material Zinc alloy: cup, steel: hinge arm
Model EN 15570
Area of Application For narrow aluminium profile doors
Hinge Type Full overlay
Cup Fixing For screw fixing
Drilling Depth Hinge cup 12.5 mm
Frame Width 19 mm
Adjustment Facility Side adjustment from -1.5 to +4.5 mm (via Hinge),
Height Adjustment : 2 mm (via Mounting Plate),
Depth Adjustment : Upto 2.8 mm (via Mounting Plate)
Opening Angle 105°
Door Thickness 20 mm
Installation Door to cabinet for quick fixing with SM quick fixing system
Supplied With Hinge, Mounting plate
