Hafele Metalla 510 Concealed Hinge

Tk. 550

Key Features :

  • With integrated soft closing mechanism in hinge cup.
  • The soft closing mechanism can be activated at an opening angle of 30°or 10° via damper shifter.
  • Salt Spray Test: 48 Hours (Passed).
  • Cycle Test: 200,000 Cycle (Passed).

Hafele Metalla 510 Concealed Hinge Features :

Product Name Metalla 510 Concealed Hinge EN 15570
Code 311.46.591
Brand Hafele
Product Type Hinge
Colour/Finish Nickel plated
Material Steel: cup and hinge arm
Model EN 15570
Area of Application For wooden doors
Hinge Type Full overlay
Cup Fixing For screw fixing
Drilling Depth Hinge cup 12 mm
Adjustment Facility Side adjustment -1.5 to +3 mm
Height adjustment -2 to +2 mm
Depth adjustment with mounting plate +2.8 mm
Opening Angle 105°
Door Thickness 15-24 mm
Installation Door to cabinet for quick fixing with SM quick fixing system
Supplied With Hinge, Mounting plate
