Hafele Fold 84 EF Concealed Hinge
Tk. 7,150
Key Features :
- 4 Pieces required for each double door.
- Adjustment facility: 3D Continuous, Side: -2 / +3 mm, Height: ±2.5 mm, Closing pressure: ±1 mm.
- Suitable for left-hand or right-hand installation.
Brand:Hafele
Hafele Fold 84 EF Concealed Hinge Specifications:
| Product Name | Fold 84 EF Concealed Hinge |
| Code | 927.91.544 |
| Brand | Hafele |
| Product Type | Door hinge |
| Color/Finish | Matt, chrome plated |
| Material | Zinc alloy |
| Door Width Max. | 900 mm |
| Model | H2 |
| Door Weight Max. | 110 lbs with 2 door hinges; ≤ 132 lbs with 3 door hinges |
| Door Height Min. | 82 11/16” with 4 hinges |
| For Door Width (Inches) | ≤ 35 7/16″ |
| For Door Thickness Min. | 1 1/4″ |
| Area of Application | For flush interior wood doors – 3D Adjustable |
| For Door Type | Wooden door leaf |
| For Frame Type | Wooden frame |
| Max. Door Weight For 2 Hinges | 45 kg |
| Max. Door Weight For 3 Hinges | 60 kg |
| Opening Angle | 180 ° |
| Door Height Max. | 2000 mm |
| Door Height Max. | 78 3/4″ |
| Door Thickness | ≥32 mm |
Brand
Hafele
