Hafele Classic 80M Straight Sliding System

Tk. 57,750

Key Features :

  • Smooth and Soft opening and closing.
  • Track and sliding gear are completely concealed.
  • Article is with: Kit, Track, Handle and all the necessery components.

Hafele Classic 80M Straight Sliding System Features :

Product Name Hafele Classic 80M Straight Sliding System
Code 940.59.003 or 940.59.009
Brand Hafele
Product Type Sliding fittings
Material Anodized
Model 80M
Door Height Max. 3000 mm
Door Width 900-1800 mm
Door Thickness Min. 25 mm
Door Weight Max. 80 kg
Running Gear Version Invisible running equipment integrated in door
Controller Installation Options Wall mounting
For Door Thickness ≥30 mm
Adjustment Facility Distance door to wall +4 mm (adjustment on both sides, for compensating uneven walls)
Number of Doors 1
Suitable For Hard floors (laminate, PVC, tiles) and soft floors (carpet, cork – use only with floor rail), Private living area
Door Processing With recess, for screw fixing
Installation Reference Ensure that the floor is level
Bottom track is required for soft floors
Prepare wall structure for top roller
Supplied With 1 running track
1 running gear
2 Soft and self closing mechanisms
1 guide track
1 floor guide
1 set of guide rollers
1 set of end caps (1 pair black, 1 pair silver colored)
2 spacers
1 floor mounted door stop (for optional use)
2 hex keys
1 open-ended spanner
